Technical Information
Specifications
Engines
Engine Type
Model Name
Total Displacement
Engine Power - SAE J1995 Gross
Rated Speed
Low Idling Speed
Honda Petrol Engine
GX690
42 cu.in.
22 hp
3,600 rpm
1,400 ± 150 rpm
Dimensions
Overall Length-Transport
(w/Std Bucket Parallel to Ground)
Overall Height
Overall Width (w/o Bucket)
Wheelbase
Hinge Pin Height at Max. Lift
Track Width STD.
Ground Clearance
Angle of Departure
Operating Weight (w/o Operator)
Rated Operating Capacity (35%)
Tipping Load
99.4 in / 2,524 mm
64 in / 1,627 mm
39.2 in / 996 mm
26 in / 660 mm
79.9 in / 2,030 mm
8.5 in / 216 mm
7.6 in / 193 mm
29.5°
2,094.4 lb / 950 kg
771.6 lb / 350 kg
2,204.6 lb / 1,000 kg
Performance
Attachment Mounting System
Battery Capacity
Auxiliary Hydraulic Flow
CII (Common Industry Interface)
12 V, 45 Ah
11 gal/min / 41 L/min
Service and Fill Capacitise
Fuel Tank Capacity
Hydraulic System
5.81 gal / 22 L
6.60 gal / 25 L
