Engines

Engine Type

Model Name
Total Displacement
Engine Power - SAE J1995 Gross
Rated Speed
Low Idling Speed

Water cooled 4 cycle

Diesel engine; Lnline; EPA Tier 4.
YANMAR 4TNV86CT
127.6 cu.in.
50 hp
2,400 rpm
950 rpm

Dimensions

Overall Length-Transport
(w/Std Bucket Parallel to Ground)
Overall Length (w/o Bucket)
Overall Height
Overall Width (w/o Bucket)
Wheelbase
Hinge Pin Height at Max. Lift
Track Width STD.
Track Width OPT.
Ground Clearance (on the side)
Angle of Departure
Operating Weight (w/o Operator)
Rated Operating Capacity (35%)
Tipping Load

139.5 in / 3,543 mm

102.6 in / 2,606 mm
62 in / 1,575 mm
45.6 in / 1,158 mm
51 in / 1,295 mm
101.5 in / 2,578 mm
9 in / 230 mm
/
3.6 in / 91 mm
30.5°
4,741 lb / 2,150 kg
2,000 lb / 907 kg
5,714 lb / 2,592 kg
