Dimensions

Overall Length-Transport
(w/Std Bucket Parallel to Ground)
Overall Length (w/o Bucket)
Overall Height
Overall Width (w/o Bucket)
Wheelbase
Hinge Pin Height at Max. Lift
Track Width STD.
Track Width OPT.
Ground Clearance
Angle of Departure
Operating Weight (w/o Operator)
Rated Operating Capacity (35%)
Tipping Load

116.9 in / 2,969 mm

106.6 in / 2,708 mm
78 in / 1,981 mm
47.9 in / 1,216 mm
47.2 in / 1,199 mm
102 in / 2,591 mm
7.8 in / 200 mm
9 in / 230 mm
8.1 in / 206 mm
18°
4,762 lb / 2,160 kg
1,666 lb / 756 kg
4,144 lb / 1,880 kg

Performance

Attachment Mounting System
Travel Speed (Fwd/Rev)
Battery Capacity
Auxiliary Hydraulic Flow
