Technical Information
Specifications
Engines
Engine Type
Model Name
Total Displacement
Engine Power - SAE J1995 Gross
Rated Speed
Low Idling Speed
Honda Petrol Engine
GX690
42 cu.in.
22 hp
3,600 rpm
1,400 ± 150 rpm
Dimensions
Overall Length-Transport
(w/Std Bucket Parallel to Ground)
Overall Height
Overall Width (w/o Bucket)
Wheelbase
Hinge Pin Height at Max. Lift
Track Width STD.
Ground Clearance
Angle of Departure
Operating Weight (with Operator)
Rated Operating Capacity (35%)
Tipping Load
97.7 in / 2,482 mm
56 in / 1,424mm
33.3 in / 848 mm
29.5 in / 750 mm
81 in / 2,058 mm
7.8 in / 200 mm
4.4 in / 111 mm
21.7°
2,800 lb / 1,270 kg
848.8 lb / 385 kg
2,425 lb / 1,100 kg
Performance
Attachment Mounting System
Battery Capacity
Auxiliary Hydraulic Flow
CII (Common Industry Interface)
12 V, 45 Ah
11 gal/min / 41 L/min
Service and Fill Capacitise
Fuel Tank Capacity
Hydraulic System
4.76 gal / 18 L
6.60 gal / 25 L
