Technical Information
Specifications
Engines
Engine Type
Model Name
Total Displacement
Engine Power - SAE J1995 Gross
Rated Speed
Low Idling Speed
Water cooled 4 cycle
Diesel engine 3-cyl; EPA Tier 4.
KUBOTA D1105
68.5 cu.in.
25 hp
3,000 rpm
900 rpm
Dimensions
Overall Length-Transport
(w/Std Bucket Parallel to Ground)
Overall Length (w/o Bucket)
Overall Height
Overall Width (w/o Bucket)
Wheelbase
Hinge Pin Height at Max. Lift
Track Width STD.
Ground Clearance
Angle of Departure
Operating Weight (w/o Operator)
Rated Operating Capacity (35%)
Tipping Load
113 in / 2,870 mm
87.9 in / 2,233 mm
63.3 in / 1,608 mm
41 in / 1,040 mm
42.7 in / 1,085 mm
82.6 in / 2,098 mm
9 in / 230 mm
11 in / 279 mm
28°
3,333 lb / 1,512 kg
1,100 lb / 500 kg
3,143 lb / 1,426 kg
Performance
Attachment Mounting System
Travel Speed (Fwd/Rev)
Battery Capacity
Main Auxiliary Hydraulic Flow
(High Flow)
Secondary Auxiliary Hydraulic Flow
(Low Flow)
CII (Common Industry Interface)
4.94 mph / 7.95 km/h
12 V, 60 Ah
12 gal/min / 45.6 L/min
​
2.27 gal/min / 8.6 L/min
Service and Fill Capacitise
Fuel Tank Capacity
Hydraulic System
9.25 gal / 35 L
9.25 gal / 35 L
